The MAGIC2 VETRO sliding door system is designed for interior sliding glass doors. This is a unique system that does not require a batten, a piece of wood, or a special finishing box to hide the batten. Silent and long operation of the sash is ensured by bearing wheels.
50 mm before full closing/opening, the system stops the door and smoothly pulls it to its final position.
Maximum load - 80 kg
Minimum leaf width - 800 mm
Maximum possible leaf width 1100 mm (maximum closed opening width 1000 mm) or 1800 mm (maximum closed opening width 1700 mm)
The thickness of the glass sheet is 10 mm.
The system is particularly convenient and quick to install.
Our advice: The only limitation of the system is that it is not recommended to install it where there is a carpet near the opening. The sash must be at least 60 mm higher than the opening.
| Weight, kg | 5.000000 |
|---|---|
| Country of origin | Italy |
| Model Name | MAGIC2 VETRO |
| Door material | Wooden doors |
| Mode of operation | Manual system |
| Mounting type | To wall |
| Brand | Terno Scorrevoli |
| Manufacturer warranty | 24 months |
| Package sizes, mm | 1400 x 100 x 100 |
